What Is JMeter Parameterization?

JMeter parameterization is the act of creating variables that will provide many different configuration options on a load testing script. It is a crucial component of creating performance tests.

For example:

  • Variables to login with different credentials on a web service
  • Variables to use different environments (dev, master, etc.)
  • Variables to search for a list of products in an e-commerce site

No wonder parametrization is one of the main aspects in performance tests creation.

Related Resource: Learn how to avoid becoming a load testing "flop" >>

Back to top

3 Approaches For JMeter Parameterization

Now we will talk about the different approaches to parameterization using JMeter.

1. Using External Files

In JMeter, one of the common ways to parametrize your performance scripts is to use a CSV file. Let’s see how this works using one of the examples that we explained earlier: login with different credentials. Let’s assume that we have a login request that works for one specific user:

A screenshot of a login request in JMeter.

We can easily parametrize that request and run it across different users. We can see that we are in need of two variables to parametrize this script: for storing the email and password..To do this we’ll need to provide a CSV file with the list of users credentials to use in the login process. (Or, you can use BlazeData).Let’s create a csv file containing different users with emails and passwords:

A screenshot of user credentials in JMeter.

Now with our CSV file created, let’s add the “CSV Data Set Config” element to our script following these steps:

Right click on Thread Group -> Add -> Config Element -> CSV Data Set Config.

Here are short explanations of ‘CSV Data Set Config’ parameters.

Name

The element name as it will be used in the JMeter tree.

Filename

The name of the input file. Relative file names are resolved based on the path of the active test plan. Absolute filenames are also supported.

File Encoding

Encoding of input file, if it’s not the platform default.

Variable Names

A list of separated variable names that will be used as a container for parsed values. If empty, the first line of the file will be interpreted as the list of variable names.

Ignore First Line

True in case you want to ignore the first line of the CSV file if the variable names are stored there.

Delimiter

A delimiter that will be used to split the parsed values from the input file.

Allow Quoted Data

True in case you want to ignore double quotes and allow such elements to contain a delimiter.

Recycle on EOF

True in case the file test plan should iterate over the file more than once. It will instruct JMeter to move the cursor to the beginning of the file.

Stop Thread on EOF

False in case of loop iteration over the CSV file and true if you want to stop the thread after reading the whole file.

Sharing Mode

  • All threads: the file is shared between all virtual users (the default).
  • Current thread group: the file will be opened once for each thread group.
  • Current thread: each file will be opened separately for each of threads.
  • Edit: all threads sharing the same identifier also share the same file.
A screenshot of CSV DataSet Config

In our case, it’s enough to add the “Filename” (user-credentials.csv) and “Variables Names” (userEmail,userPassword) config values and leave the rest to their default settings.

The last step we have to take is to parametrize the login request with our new variables. This can be done by replacing the initial values with appropriate variables from the “Variable Names” configuration field of the CSV Data Set Config, like this:

A screenshot of variables in CSV Data Set Config.

If we run our test script now, JMeter will replace these variables with values from the ‘user-credentials.csv’ file. Each JMeter virtual user will receive credentials from one of the csv file lines.

The login request by the first and second users will look like this:

A screenshot of View Results Tree.
A screenshot of a login request in View Results Tree.

2. Using Databases

Another way to parametrize your performance scripts is to use database data. JDBC is an application programming interface that defines how a client can access a database and we’ll be using it to parametrize our JMeter scripts.

First of all, download the relevant JDBC driver to your database. For example, the mysql driver can be found here. Then, you need to add the .jar file to the test-plan by using the form below:

A screenshot of a test plan in JMeter.

After that, configure the database connection by using the ‘JDBC Connection Configuration’ element. Add it following these steps:

Right click on Thread Group -> Add -> Config Element -> JDBC Connection Configuration

A screenshot of the JDBC Connection Configuration in JMeter.

‘JDBC Connection Configuration’ parameters include the following.

Name

The name of the connection configuration that will be shown in the thread group tree.

Variable Name

The name that will be used as a unique identifier for the db connection (multiple connections can be used and each one will be tied to a different name).

Max Number of Connections

The maximum number of connections allowed in the connection pool. In case of 0, each thread will get its own pool with a single connection in it.

Max Wait (ms)

Pool throws an error if the specified timeout is exceeded during db connection.

Time Between Eviction Runs (ms)

The number of milliseconds to pause between runs of the thread that evicts unused connections from the db pool.

Auto Commit

Yes to turn auto commit for related db connections.

Test While Idle

check idle connections before an effective request is detected. More details: here.

Soft Min Evictable Idle Time(ms)

The period of time during which a specified connection might be idle in the db pool before it can be evicted. More details: here.

Validation Query

Health check query that will be used to verify if the database is still responding.

Database URL

JDBC connection string for the database. Examples on this link.

JDBC Driver class

Appropriate name of driver class (specific for each db). For example, ‘com.mysql.jdbc.Driver’ for MySql db.

Username

Database username.

Password

Database password (will be stored unencrypted in the test plan).

In our case we need to setup the mandatory fields only:

  • Variable name Bound to Pool
  • Database URL
  • JDBC Driver class
  • Username
  • Password

The rest of the fields in the screen can be left as defaults:

A screenshot of how to fill out the fields in the JDBC Connection Configuration.

Let’s assume that we stored test user credentials in the database:

A screenshot of user credentials in the database.

Now when the database connection is configured, we can add the JDBC request itself and use its query to get all the credentials from database:

Right click on Thread Group -> Add -> Sample -> JDBC Request

By using the ‘Select Statement’ query and ‘Variable Names’ we can parse the response to custom variables.

A screenshot of a query and variable names.

We will now have JMeter variables that can be used further in subsequent requests. Specified variables will be created with incremental suffix (userEmail_1, userEmail_2, userEmail_3…..).

To use these variables in the ‘Login request’, we need to add a counter that will be used to access the right values from the JDBC query response. To add the ‘Counter’ element in JMeter follow this steps:

Right click on Thread Group -> Add -> Config Element -> Counter

A screenshot of login using the CSV file.

After that, we can update the ‘Login request’ using the “__V” function. This returns the result of evaluating a variable name expression and can be used to evaluate nested variable references. It is shown here:

A screenshot of an HTTP request for login.

The specified configuration is enough to use database values to run the script across different users:

A screenshot of database values for different users.
A screenshot of a login request.

3. Using the ‘Parameterized Controller’ Plugin

If you need to execute a repeating sequence of the same action with different parameters, you can also use the ‘Parameterized Controller’ plugin. This controller allows us to configure a set of variables to be used in every step added into that controller. First of all, you need to install the ‘Parameterized Controller’ plugin as it is not included into the JMeter core. Installation steps of that process can be found here.

Let’s move the ‘Login Request’ into a separate controller and disable it (right-click it and select "Disable"). This is the most preferable way to have a modules container inside your test plan, but also to keep them referenceable so they can be used.

After the installation is over, you can add two ‘Parameterized Controller’ controllers with different user credentials stored in variables:

Right click on Thread Group -> Add -> Logic Controller -> Parameterized Controller



A screenshot of a parameterized controller.



Parameterized Controllers contains the ‘User Defined Variables’ section, where you can specify your parameters. Put the credentials of the first user in the first parameterized controller and the second user credentials in the second parameterized controller.



A screenshot of parameterized controllers in JMeter.



Now we’ll need to add references to the ‘Reusable Controller’ inside each ‘Parameterized Controller’.

We can do this by adding a ‘Module Controller’, this controller will run all steps in a selected module.

In this case it will call the ‘Login request’ with different parameters. To create a ‘Module Controller’ follow these steps:

Right click on ‘Parameterized Controller’ -> ‘Add’ -> ‘Logic Controller’ -> ‘Module Controller’



A screenshot of a reusable controller.



When running your script, you will see that the ‘Login request’ triggered each of the parameterized controllers separately. It can be very useful in case you need to run your script across different combinations of input parameters.



A screenshot of View Results Tree in JMeter.
Back to top

Final Thoughts on JMeter Parameterization

Correlations operate side by side with parametrization. After parameterization, correlation is the process of capturing and storing the dynamic response from the server and passing them on correctly to subsequent requests.

You can learn more from this blog post: “How to Handle Correlation in JMeter”.

You can handle correlations manually, using extractors to save data in variables, or automatically, using a plugin called “Correlation Recorder”. This plugin enables you to easily load test applications with dynamic variables. The plugin records the dynamic variables and automatically correlates them during the recording time, instead of having to manually apply correlations to each request and response.

To learn more about the “Correlation Recorder” plugin visit this post.

That’s it! You now know a number of ways to parameterize your tests. To learn more tips and hacks for building your JMeter testing scripts, try out our free BlazeMeter University.
