GitHub + Jenkins: How to Integrate Your GitHub Repository to Your Jenkins Project

Open Source Automation

Jenkins and GitHub are two powerful tools on their own, but what about using them together? In this blog, learn about the benefits of a Jenkins integration with GitHub and how to set up the integration on your own for GitHub Jenkins harmony.

Table of Contents:

Can You Use Jenkins With GitHub?

You can and should use Jenkins with GitHub to save time and keep your project up-to-date.

One of the basic steps of implementing CI/CD is integrating your SCM (Source Control Management) tool with your CI tool. This saves you time and keeps your project updated all the time. One of the most popular and valuable SCM tools is GitHub.

📕 Related Reading: Explore Five Advantages Your Peers are Discovering with Continuous Testing >>

What is GitHub?

GitHub is a Git-based repository host, commonly used for open-source projects. GitHub enables code collaboration, hosting, and versioning.

What is Jenkins?

Jenkins is an open-source Continuous Integration and Continuous Deployment (CI/CD) tool for automating the software development life cycle (SDLC). With Jenkins testing, teams can automate the building, testing, and deploying of code.

Why Integrate GitHub + Jenkins?

A Jenkings integration with GitHub will improve the efficiency of building, testing, and deploying your code.

The integration presented in this blog post will teach you how to schedule your build, pull your code and data files from your GitHub repository to your Jenkins machine, and automatically trigger each build on the Jenkins server after each Commit on your Git repository.

But first, let’s configure the Jenkins and GitHub integration. Let's begin with the GitHub side!

How to Set Up the Jenkins + GitHub Integration

Configuring GitHub

Step 1: go to your GitHub repository and click on ‘Settings’.

GitHub repo settings

Step 2: Click on Webhooks and then click on ‘Add webhook’.

add github webhook

Step 3: In the ‘Payload URL’ field, paste your Jenkins environment URL. At the end of this URL add /github-webhook/. In the ‘Content type’ select: ‘application/json’ and leave the ‘Secret’ field empty.

paste jenkins environment url to payload url in github

Step 4: In the page ‘Which events would you like to trigger this webhook?’ choose ‘Let me select individual events.’ Then, check ‘Pull Requests’ and ‘Pushes’. At the end of this option, make sure that the ‘Active’ option is checked and click on ‘Add webhook’.

activate "add webhook" option

checked pull requests and push options

We're done with the configuration on GitHub’s side! Now let's move on to Jenkins.

Configuring Jenkins

Step 5: In Jenkins, click on ‘New Item’ to create a new project.

jenkins new item

Step 6: Give your project a name, then choose ‘Freestyle project’ and finally, click on ‘OK’.

jenkins freestyle project

Step 7: Click on the ‘Source Code Management’ tab.

jenkins ‘Source Code Management’ tab

Step 8: Click on Git and paste your GitHub repository URL in the ‘Repository URL’ field.

pasting github url into jenkins repository url field

Step 9: Click on the ‘Build Triggers’ tab and then on the ‘GitHub hook trigger for GITScm polling’. Or, choose the trigger of your choice.

triggering builds in jenkins

That's it! Your GitHub repository is integrated with your Jenkins project. With this Jenkins GitHub integration, you can now use any file found in the GitHub repository and trigger the Jenkins job to run with every code commit.

For example, I will show you how to run a Taurus script that I uploaded to my GitHub repository from my Jenkins project. Taurus is an open source load testing solution, enabling developers to run load testing scripts from sophisticated platforms like JMeter and Selenium, but with a simple YAML code.

Triggering the Jenkins GitHub Integration With Every Code Commit

Step 10: Click on the ‘Build’ tab, then click on ‘Add build step’ and choose ‘Execute shell’.

execute shell

Step 11: To run a Taurus test, simply use the ‘bzt’ command, followed by the name of your YML file and click on ‘Save’.

run taurus in jenkins with github

Step 12: Go back to your GitHub repository, edit the Taurus script and commit the changes. We will now see how Jenkins ran the script after the commit.

run jenkins script after commit

Step 13: Go back to your Jenkins project and you'll see that a new job was triggered automatically from the commit we made at the previous step. Click on the little arrow next to the job and choose ‘Console Output’.

console output

Step 14: You can see that Jenkins was able to pull the Taurus script and run it!

jenkins github integration for running taurus script

Bottom Line

Congratulations! You have now set up a fully functioning Jenkins GitHub integration. Every time you publish your changes to Github, GitHub will trigger your new Jenkins job.

Once the GitHub plugin is fully installed and integrated into your Jenkins project, you have completed a very crucial step towards the full CI process. Now, you can proceed to the testing phase. To complete the full CI process, integrate your load testing into your CI tool. Using the BlazeMeter integration with Jenkins, incorporating load testing into your CI/CD pipeline has never been simpler.
